WTH is it?

If I had to venture a guess, I would say it is a CNC panel. If each of the circuit boards is an individual motor driver and each of the power supplies powers a single stepper or servo. It would have been decent sized motors--the CNC cue machine I made uses one power supply about that size for three size 23 motors.


Well-known member
So broken off of something or another for the copper inside?

If it was, they took the wrong stuff. There probably wasn't ten pounds of stranded wire, 12-18ga.. The power supplies start at about $30 each (off brand, a Mean Well would probably be over $50). Not a ton of money involved in what is shown, but having extra power supplies is always useful.

Now that I think about it, it may have come from a led lighting system, also--anything that takes DC power and some control.

I'm guessing it was scrapped equipment of some sort.
